4-way switcher unit that allows the distribution of a stereo amplifier. Simply connect the output of an amplifier to the selector box, this output can then be distributed to up to four different stereo speaker sets in multiple locations, each speaker set can be individually activated via the push buttons on the front of the unit. Ideally suited for buildings where an independent sound control is required for different rooms or zones.

Specifications

Enables four pairs of speakers to be connected to a single stereo amplifier
Heavy duty push-buttons
Built-in overload protection
Designed for 4-16 ohms speakers
Spring clip terminals
Wiring gauge:14 to 22 gauge
Input:1 x stereo
Output:4 x stereo
Power per channel:140W max.
Dimensions:215 x 110 x 45mm
Weight:1.2kg
