The FTP3HP RGB LED DMX Driver is suitable for most types of 24V RGB flexible colour tapes requiring constant voltage control. After connecting RGB LED tape with this controller you can utilise the manual dimming mode or built-in programs via the on-board dipswitches. Further control can be facilitated by the units DMX input.
Constant voltage driver for 12-24V RGB LED flexible colour strip DMX and manual dimming mode plus built-in programs Dipswitch mode/DMX selection Refresh rate: 7.8kHz Housed in a compact rugged metal casing Phoenix type plug in terminals 3 channel operation Maximum output: 288W
Power supply: DC 12-24V Maximum total output: 12A (144W at 12Vdc 288W at 24Vdc) IP rating: IP20 Dimensions (H x W x D): 25 x 115 x 55mm Weight: 0.1kg
Constant voltage driver for 12-24V RGB LED flexible colour strip DMX and manual dimming mode plus built-in programs Dipswitch mode/DMX selection Refresh rate: 7.8kHz Housed in a compact rugged metal casing Phoenix type plug in terminals 3 channel operation Maximum output: 288W
Power supply: DC 12-24V Maximum total output: 12A (144W at 12Vdc 288W at 24Vdc) IP rating: IP20 Dimensions (H x W x D): 25 x 115 x 55mm Weight: 0.1kg
LEDJ Flexoled FTP3HP RGB LED DMX Driver
Brand: LEDJ
SKU: FLEX30
Regular price
£39.99
Pickup available at Venutec
Usually ready in 24 hours
LEDJ Flexoled FTP3HP RGB LED DMX Driver
-
Venutec
Pickup availableUsually ready in 24 hours
3 Waterside Court
Bone Lane
Newbury RG14 5SH
United Kingdom447404920360
Need help with choosing the right product?
Click here to reach out to one of our experts.
The FTP3HP RGB LED DMX Driver is suitable for most types of 24V RGB flexible colour tapes requiring constant voltage control. After connecting RGB LED tape with this controller you can utilise the manual dimming mode or built-in programs via the on-board dipswitches. Further control can be facilitated by the units DMX input.
Constant voltage driver for 12-24V RGB LED flexible colour strip DMX and manual dimming mode plus built-in programs Dipswitch mode/DMX selection Refresh rate: 7.8kHz Housed in a compact rugged metal casing Phoenix type plug in terminals 3 channel operation Maximum output: 288W
Power supply: DC 12-24V Maximum total output: 12A (144W at 12Vdc 288W at 24Vdc) IP rating: IP20 Dimensions (H x W x D): 25 x 115 x 55mm Weight: 0.1kg
Constant voltage driver for 12-24V RGB LED flexible colour strip DMX and manual dimming mode plus built-in programs Dipswitch mode/DMX selection Refresh rate: 7.8kHz Housed in a compact rugged metal casing Phoenix type plug in terminals 3 channel operation Maximum output: 288W
Power supply: DC 12-24V Maximum total output: 12A (144W at 12Vdc 288W at 24Vdc) IP rating: IP20 Dimensions (H x W x D): 25 x 115 x 55mm Weight: 0.1kg
