The Lynx LUKA-226 is a 2-input 6-output professional loudspeaker processor featuring 64-bit DSP 32-bit conversion FIR filtering AES3 digital input and advanced routing modes. Designed for high-performance PA systems requiring flexible matrixing and powerful loudspeaker protection.
2 analogue inputs + AES3 2-channel digital input 6 analogue outputs 64-bit DSP internal resolution 32-bit AD/DA converters max input +24 dBu Dynamic range: 121 dB (in) / 120 dB (out) FIR processing up to 1000 taps per output User EQ: High-Pass + 10 Parametric Mode EQ: High-Pass/Low-Pass + 10 Parametric Output EQ: High-Pass/Low-Pass + 12 Parametric + FIR custom Full PEQ filter set including AllPass RMS limiters + Peak limiters per output Input matrix with Simple / Basic / Advanced routing Backup-priority input selection Delay up to 206 ms (≈70 m) on ins/outs 999 presets: User Snapshot & Speaker USB & Ethernet remote control 320×170 IPS colour display joystick + dedicated mute/edit buttons
Inputs: 2× analogue balanced XLR AES3 (2-channel) Input impedance: 10kΩ balanced Outputs: 6× analogue balanced XLR Output impedance: 200Ω balanced Max output level: +24dBu Audio frequency range: 10Hz – 24kHz Latency: 1.17ms Power: 85–240V AC 20W Dimensions: 483 × 45 × 200mm Weight: 3kg Software link: OCS control software
Lynx Pro-Audio Loudspeaker Processor 64 Bit 2 In 6 Out LUKA-226
Brand: Lynx Pro-Audio
SKU: LYNX071
Pickup available at Venutec
Usually ready in 24 hours
Lynx Pro-Audio Loudspeaker Processor 64 Bit 2 In 6 Out LUKA-226
-
Venutec
Pickup availableUsually ready in 24 hours
3 Waterside Court
Bone Lane
Newbury RG14 5SH
United Kingdom447404920360
Need help with choosing the right product?
The Lynx LUKA-226 is a 2-input 6-output professional loudspeaker processor featuring 64-bit DSP 32-bit conversion FIR filtering AES3 digital input and advanced routing modes. Designed for high-performance PA systems requiring flexible matrixing and powerful loudspeaker protection.
2 analogue inputs + AES3 2-channel digital input 6 analogue outputs 64-bit DSP internal resolution 32-bit AD/DA converters max input +24 dBu Dynamic range: 121 dB (in) / 120 dB (out) FIR processing up to 1000 taps per output User EQ: High-Pass + 10 Parametric Mode EQ: High-Pass/Low-Pass + 10 Parametric Output EQ: High-Pass/Low-Pass + 12 Parametric + FIR custom Full PEQ filter set including AllPass RMS limiters + Peak limiters per output Input matrix with Simple / Basic / Advanced routing Backup-priority input selection Delay up to 206 ms (≈70 m) on ins/outs 999 presets: User Snapshot & Speaker USB & Ethernet remote control 320×170 IPS colour display joystick + dedicated mute/edit buttons
Inputs: 2× analogue balanced XLR AES3 (2-channel) Input impedance: 10kΩ balanced Outputs: 6× analogue balanced XLR Output impedance: 200Ω balanced Max output level: +24dBu Audio frequency range: 10Hz – 24kHz Latency: 1.17ms Power: 85–240V AC 20W Dimensions: 483 × 45 × 200mm Weight: 3kg Software link: OCS control software
