The Neutrik NAC3MPX-TRUE1 is a rugged locking 16A chassis connector from the premium powerCON® TRUE1 series engineered for outdoor industrial and AV environments requiring high durability and safety. With Certified Breaking Capacity (CBC) this true mains connector can be safely connected or disconnected under load. Featuring an airtight twist-lock design it ensures full IP65 IP66 and IP67 protection when mated or capped. Built from UV-resistant PA 6.6 with stainless steel locking and certified by ENEC VDE UL and CSA the NAC3MPX-TRUE1 is trusted for global power connectivity in demanding applications.
Certified Breaking Capacity (CBC) for live connect/disconnect IP65/IP66/IP67 ingress protection when mated or sealed High-impact UV-resistant PA 6.6 polyamide shell ENEC VDE UL and CSA certified Stainless steel locking for reliable twist-lock engagement Rated for over 5000 mating cycles Suitable for harsh AV lighting and industrial installations Extended operating temperature: -30°C to +80°C
Rated Current: 16A / 250V AC (Europe) 20A / 250V AC (USA/Canada) Contacts: 2 + PE Contact Resistance: ≤ 2 mΩ Dielectric Strength: 4 kV DC / 2.8 kV AC Insulation Resistance: > 1 GΩ (after damp/heat test) Wire Size: 2.5 mm² / 12 AWG Mating Cycles: > 5000 Contact Plating: 2 μm Ag Contacts: Copper Alloy Locking Element: Stainless Steel Shell: Polyamide (PA 6.6) Flammability: UL 94 V-0 Protection Class: IP65 / IP66 / IP67 (mated or sealed) UV Resistance: F1 rated material Temperature Range: -30°C to +80°C (IEC 61984) -5°C to +40°C (IEC 60320-1)
Certified Breaking Capacity (CBC) for live connect/disconnect IP65/IP66/IP67 ingress protection when mated or sealed High-impact UV-resistant PA 6.6 polyamide shell ENEC VDE UL and CSA certified Stainless steel locking for reliable twist-lock engagement Rated for over 5000 mating cycles Suitable for harsh AV lighting and industrial installations Extended operating temperature: -30°C to +80°C
Rated Current: 16A / 250V AC (Europe) 20A / 250V AC (USA/Canada) Contacts: 2 + PE Contact Resistance: ≤ 2 mΩ Dielectric Strength: 4 kV DC / 2.8 kV AC Insulation Resistance: > 1 GΩ (after damp/heat test) Wire Size: 2.5 mm² / 12 AWG Mating Cycles: > 5000 Contact Plating: 2 μm Ag Contacts: Copper Alloy Locking Element: Stainless Steel Shell: Polyamide (PA 6.6) Flammability: UL 94 V-0 Protection Class: IP65 / IP66 / IP67 (mated or sealed) UV Resistance: F1 rated material Temperature Range: -30°C to +80°C (IEC 61984) -5°C to +40°C (IEC 60320-1)
Neutrik powerCON TRUE1 Chassis Connector NAC3MPX-TRUE1
Brand: Neutrik
SKU: CONN1269
Regular price
£16.99
Pickup available at Venutec
Usually ready in 24 hours
Neutrik powerCON TRUE1 Chassis Connector NAC3MPX-TRUE1
-
Venutec
Pickup availableUsually ready in 24 hours
3 Waterside Court
Bone Lane
Newbury RG14 5SH
United Kingdom447404920360
Need help with choosing the right product?
Click here to reach out to one of our experts.
The Neutrik NAC3MPX-TRUE1 is a rugged locking 16A chassis connector from the premium powerCON® TRUE1 series engineered for outdoor industrial and AV environments requiring high durability and safety. With Certified Breaking Capacity (CBC) this true mains connector can be safely connected or disconnected under load. Featuring an airtight twist-lock design it ensures full IP65 IP66 and IP67 protection when mated or capped. Built from UV-resistant PA 6.6 with stainless steel locking and certified by ENEC VDE UL and CSA the NAC3MPX-TRUE1 is trusted for global power connectivity in demanding applications.
Certified Breaking Capacity (CBC) for live connect/disconnect IP65/IP66/IP67 ingress protection when mated or sealed High-impact UV-resistant PA 6.6 polyamide shell ENEC VDE UL and CSA certified Stainless steel locking for reliable twist-lock engagement Rated for over 5000 mating cycles Suitable for harsh AV lighting and industrial installations Extended operating temperature: -30°C to +80°C
Rated Current: 16A / 250V AC (Europe) 20A / 250V AC (USA/Canada) Contacts: 2 + PE Contact Resistance: ≤ 2 mΩ Dielectric Strength: 4 kV DC / 2.8 kV AC Insulation Resistance: > 1 GΩ (after damp/heat test) Wire Size: 2.5 mm² / 12 AWG Mating Cycles: > 5000 Contact Plating: 2 μm Ag Contacts: Copper Alloy Locking Element: Stainless Steel Shell: Polyamide (PA 6.6) Flammability: UL 94 V-0 Protection Class: IP65 / IP66 / IP67 (mated or sealed) UV Resistance: F1 rated material Temperature Range: -30°C to +80°C (IEC 61984) -5°C to +40°C (IEC 60320-1)
Certified Breaking Capacity (CBC) for live connect/disconnect IP65/IP66/IP67 ingress protection when mated or sealed High-impact UV-resistant PA 6.6 polyamide shell ENEC VDE UL and CSA certified Stainless steel locking for reliable twist-lock engagement Rated for over 5000 mating cycles Suitable for harsh AV lighting and industrial installations Extended operating temperature: -30°C to +80°C
Rated Current: 16A / 250V AC (Europe) 20A / 250V AC (USA/Canada) Contacts: 2 + PE Contact Resistance: ≤ 2 mΩ Dielectric Strength: 4 kV DC / 2.8 kV AC Insulation Resistance: > 1 GΩ (after damp/heat test) Wire Size: 2.5 mm² / 12 AWG Mating Cycles: > 5000 Contact Plating: 2 μm Ag Contacts: Copper Alloy Locking Element: Stainless Steel Shell: Polyamide (PA 6.6) Flammability: UL 94 V-0 Protection Class: IP65 / IP66 / IP67 (mated or sealed) UV Resistance: F1 rated material Temperature Range: -30°C to +80°C (IEC 61984) -5°C to +40°C (IEC 60320-1)
