Solid conductor twisted pair data cable supplied in dispensing box and marked at 1 metre intervals. Suitable for high speed data transmission such as Gigabit Ethernet applications.
Solid copper clad aluminium conductor
Supplied in an easy-pull dispensing box
Conductor:Solid CCA
Strands:8 x 1/0.51mmØ ±2%
CSA:8 x 0.204mm²
Cable : diameter:5mmØ
Insulation:HDPE 0.19mm thickness
Sheath:PVC 0.5mm thickness
Impedance:100 Ohms (±15)
DC resistance @ 20°C:<35 Ohms/100mt
Return loss:>20dB @ 100m
NEXT:>40dB @ 100m
PSNEXT:>38dB @ 100m
Cable colour:Grey
Length:305m
Weight:6kg
Specifications
Passes Cat5e fluke test 100m at 100MHzSolid copper clad aluminium conductor
Supplied in an easy-pull dispensing box
Conductor:Solid CCA
Strands:8 x 1/0.51mmØ ±2%
CSA:8 x 0.204mm²
Cable : diameter:5mmØ
Insulation:HDPE 0.19mm thickness
Sheath:PVC 0.5mm thickness
Impedance:100 Ohms (±15)
DC resistance @ 20°C:<35 Ohms/100mt
Return loss:>20dB @ 100m
NEXT:>40dB @ 100m
PSNEXT:>38dB @ 100m
Cable colour:Grey
Length:305m
Weight:6kg
Mercury Economy Cat5e U/UTP Network Cable 305m Grey
Brand: Mercury
SKU: 808.021UK
Regular price
£45.99
Pickup available at Venutec
Usually ready in 24 hours
Mercury Economy Cat5e U/UTP Network Cable 305m Grey
-
Venutec
Pickup availableUsually ready in 24 hours
3 Waterside Court
Bone Lane
Newbury RG14 5SH
United Kingdom447404920360
