2 input, 5 zone mixer with individual volumes for both inputs and a mono switch for each zone. All inputs and outputs are stereo via balanced XLR connectors. Acts as the central mix and control in an installation serving up to 5 separate stereo speaker zones.

Specifications

Fully balanced XLR connections
2 inputs to 5 zones
Mono selectable for each zone
Power supply:115/230Vac 50/60Hz (IEC)
Inputs:Line 1 L+R, Line 2 L+R, balanced XLRF
Outputs:Zone 1 to 5 L+R, balanced XLRM
Input impedance:40k Ohms
Output impedance:220 Ohms
Frequency response:20Hz - 25kHz, +0/-1dB
Signal to noise ratio:>100dB
THD:<0.005%
Dimensions:483 x 175 x 44mm
Weight:2.2kg
