Vizi Pix Z19 is a high-performance moving head wash fixture engineered to deliver vibrant colour effects and captivating visuals for professional stages and live events.
Equipped with nineteen 30W RGBL LEDs the fixture offers advanced virtual CMY colour mixing a wide motorised zoom range and smooth electronic dimming making it ideal for crafting everything from precise beams to expansive washes. Its dynamic design is enhanced by 30 RGB background LEDs and a 40-light RGB LED ring. Both foreground and background LEDs are fully pixel-mappable for complex patterns and dazzling effects. Built-in pixel effect programs and colour macros further expand its creative possibilities.
Control options include DMX Art-Net sACN RDM and the Aria X2 wireless system for seamless integration and over-the-air updates. Adjustable dim curves selectable LED refresh rates and a white colour temperature range from 2700K to 10000K ensure flexibility across diverse environments from live performances to broadcast studios.
With robust pan/tilt locks durable Seetronic power and data connections and a lightweight low-maintenance build the Vizi Pix Z19 is the ultimate tool for creating striking professional-grade lighting displays with unmatched precision and versatility.
2 year warrantyPrimary Light Source: 19 x 30W quad-colour LEDs (RGBL) Adjustable beam angle: 7°- 42° Adjustable field angle: 9°- 60° 93750 Lux @ 2m CRI: 86 Full pixel mapping capabilitiesBackground Light Source: 30 x 0.5W tri-colour SMD 5050 LEDs (RGB) Full pixel mapping capabilitiesRing Light Source: 40 x 0.5W tri-colour SMD 5050 LEDs (RGB) 3 pixel zone mapping capabilitiesControl protocols: DMX Art-net and sACN DMX channels: 32/43/58/58/123/133 or 203 selectable Virtual CMY DMX control modes Virtual foreground and background colour wheel control Built-in colour macros Colour temperature presets Wireless control (Aria X2 Management System) Manual control and primary/secondary modes plus built-in programs Pan/tilt transit lock and auto correction 16-Bit pan/tilt positioning Pan: 540° or 630° selectable Tilt: 265°0 100% dimming 6 dimming modes: Standard stage TV architectural theatre and stage 2 Variable strobe Quick release omega clamps included RDM (Remote Device Management) 6 button menu with LCD display PowerTwist TR1 input/output 5-Pin XLR input/output RJ45 input/output Fan cooled
Manufacturer Part Number: 1237000363 Power consumption: 690W Power supply: 100~240V 50/60Hz Dimensions (H x W x D): 408 x 310 x 230mm Weight: 10.1kg
ADJ Vizi Pix Z19
Brand: ADJ
SKU: ADJ1237000363
Pickup available at Venutec
Usually ready in 24 hours
ADJ Vizi Pix Z19
-
Venutec
Pickup availableUsually ready in 24 hours
3 Waterside Court
Bone Lane
Newbury RG14 5SH
United Kingdom447404920360
Need help with choosing the right product?
Vizi Pix Z19 is a high-performance moving head wash fixture engineered to deliver vibrant colour effects and captivating visuals for professional stages and live events.
Equipped with nineteen 30W RGBL LEDs the fixture offers advanced virtual CMY colour mixing a wide motorised zoom range and smooth electronic dimming making it ideal for crafting everything from precise beams to expansive washes. Its dynamic design is enhanced by 30 RGB background LEDs and a 40-light RGB LED ring. Both foreground and background LEDs are fully pixel-mappable for complex patterns and dazzling effects. Built-in pixel effect programs and colour macros further expand its creative possibilities.
Control options include DMX Art-Net sACN RDM and the Aria X2 wireless system for seamless integration and over-the-air updates. Adjustable dim curves selectable LED refresh rates and a white colour temperature range from 2700K to 10000K ensure flexibility across diverse environments from live performances to broadcast studios.
With robust pan/tilt locks durable Seetronic power and data connections and a lightweight low-maintenance build the Vizi Pix Z19 is the ultimate tool for creating striking professional-grade lighting displays with unmatched precision and versatility.
2 year warrantyPrimary Light Source: 19 x 30W quad-colour LEDs (RGBL) Adjustable beam angle: 7°- 42° Adjustable field angle: 9°- 60° 93750 Lux @ 2m CRI: 86 Full pixel mapping capabilitiesBackground Light Source: 30 x 0.5W tri-colour SMD 5050 LEDs (RGB) Full pixel mapping capabilitiesRing Light Source: 40 x 0.5W tri-colour SMD 5050 LEDs (RGB) 3 pixel zone mapping capabilitiesControl protocols: DMX Art-net and sACN DMX channels: 32/43/58/58/123/133 or 203 selectable Virtual CMY DMX control modes Virtual foreground and background colour wheel control Built-in colour macros Colour temperature presets Wireless control (Aria X2 Management System) Manual control and primary/secondary modes plus built-in programs Pan/tilt transit lock and auto correction 16-Bit pan/tilt positioning Pan: 540° or 630° selectable Tilt: 265°0 100% dimming 6 dimming modes: Standard stage TV architectural theatre and stage 2 Variable strobe Quick release omega clamps included RDM (Remote Device Management) 6 button menu with LCD display PowerTwist TR1 input/output 5-Pin XLR input/output RJ45 input/output Fan cooled
Manufacturer Part Number: 1237000363 Power consumption: 690W Power supply: 100~240V 50/60Hz Dimensions (H x W x D): 408 x 310 x 230mm Weight: 10.1kg
