Offering a powerful output of up to 16000 lumens the ADJ Protégé XM is a professional-grade LED-powered moving head spot designed to provide lighting designers with exceptional brightness versatility and creative potential from a relatively compact fixture. At its core is a 350-watt white LED engine with a native colour temperature of 8000K producing an intense punchy beam that cuts through in even the most demanding environments. Its precision-engineered optics deliver stunning visual clarity and crisp projections while a motorized zoom ranging from 3.8° to 44° allows seamless transitions between tight beams and a wide spot.
The Protégé XM’s advanced colour system includes disc-based CMY colour mixing complemented by two colour wheels each loaded with nine vibrant dichroic filters including a 2700K CTO filter for warm white output. Creative flexibility is enhanced further through dual rotating GOBO wheels – each featuring seven high-definition replaceable glass GOBOs—allowing for intricate layered textures and dynamic mid-air effects. Its extensive effects engine features dual 6-facet prisms (linear and circular) which can be overlaid for complex refraction patterns as well as two variable frost filters for smooth diffusion and an animation wheel for evolving motion graphics.
Robust pan/tilt locks 360° continuous pan rotation and 3-phase motors ensure easy transport as well as smooth precise and lightning-fast movement. Built to succeed ADJ’s popular Focus Spot 6Z the Protégé XM sets a new benchmark for compact high-output LED spot fixtures – ideal for medium-sized stages venues houses of worship and event productions demanding both power and finesse.
Engineered for professional environments the Protégé XM offers a full suite of modern control and connectivity options. It features both 5-pin DMX and RJ45 input and thru sockets with support for the sACN and Art-Net network protocols. It also offers integrated Aria X2 next generation wireless technology that offers both cable free DMX control and NFC-enabled remote fixture management with OTA firmware updates for quick configuration.
2 year warranty 350W White LED Engine Colour Temperature: 8000K (+/-200K) Motorized zoom range: 3.7°–43° Motorized Focus 16000 Total Lumens CRI: 70 6-Facet Circular & 6-Facet Linear Rotating Prisms 2 x Frost Filters (Light and Heavy) 2 x Rotating Gobo Wheels: Each with 7 Interchangeable Glass Gobos Animation Wheel on Movable Arm Disc-Based CMY Colour Mixing 2 Colour wheels: Each with 9 colours + open Colour Wheel 1: Red Blue Green Orange Quad Colour Lime Amber Magenta Congo Blue Colour Wheel 2: Dark Red Midnight Blue Light Turquoise Pink UV Quad Colour High CRI CTO 2700K CTC (Colour Temp. Correction) Control protocols: DMX RDM sACN and ArtNet 3 DMX Channel Modes (Basic / Standard / Extended) Aria X2 Wireless Management System NFC System Pan/tilt transit lock Pan/tilt auto correction 16-Bit pan/tilt positioning Pan: 540°/360° (360° Continuous Pan Rotation Option) Tilt: 270° 3 Phase Motors 0–100% dimming Variable strobe Quick release omega clamps included 6 Button Touch Control Panel Full Colour 180° Reversible LCD Menu Display IP65 Power Locking In/Thru Seetronic 5-pin XLR Locking DMX In/Thru Seetronic RJ45 Locking In/Thru Fan cooled
Power consumption: 675W Power supply: 100~240V 50/60Hz Dimensions (H x W x D): 566.5 x 368 x 248mm Weight: 22kg
ADJ Protege XM
Brand: ADJ
SKU: ADJ1237000422
Need help with choosing the right product?
Offering a powerful output of up to 16000 lumens the ADJ Protégé XM is a professional-grade LED-powered moving head spot designed to provide lighting designers with exceptional brightness versatility and creative potential from a relatively compact fixture. At its core is a 350-watt white LED engine with a native colour temperature of 8000K producing an intense punchy beam that cuts through in even the most demanding environments. Its precision-engineered optics deliver stunning visual clarity and crisp projections while a motorized zoom ranging from 3.8° to 44° allows seamless transitions between tight beams and a wide spot.
The Protégé XM’s advanced colour system includes disc-based CMY colour mixing complemented by two colour wheels each loaded with nine vibrant dichroic filters including a 2700K CTO filter for warm white output. Creative flexibility is enhanced further through dual rotating GOBO wheels – each featuring seven high-definition replaceable glass GOBOs—allowing for intricate layered textures and dynamic mid-air effects. Its extensive effects engine features dual 6-facet prisms (linear and circular) which can be overlaid for complex refraction patterns as well as two variable frost filters for smooth diffusion and an animation wheel for evolving motion graphics.
Robust pan/tilt locks 360° continuous pan rotation and 3-phase motors ensure easy transport as well as smooth precise and lightning-fast movement. Built to succeed ADJ’s popular Focus Spot 6Z the Protégé XM sets a new benchmark for compact high-output LED spot fixtures – ideal for medium-sized stages venues houses of worship and event productions demanding both power and finesse.
Engineered for professional environments the Protégé XM offers a full suite of modern control and connectivity options. It features both 5-pin DMX and RJ45 input and thru sockets with support for the sACN and Art-Net network protocols. It also offers integrated Aria X2 next generation wireless technology that offers both cable free DMX control and NFC-enabled remote fixture management with OTA firmware updates for quick configuration.
2 year warranty 350W White LED Engine Colour Temperature: 8000K (+/-200K) Motorized zoom range: 3.7°–43° Motorized Focus 16000 Total Lumens CRI: 70 6-Facet Circular & 6-Facet Linear Rotating Prisms 2 x Frost Filters (Light and Heavy) 2 x Rotating Gobo Wheels: Each with 7 Interchangeable Glass Gobos Animation Wheel on Movable Arm Disc-Based CMY Colour Mixing 2 Colour wheels: Each with 9 colours + open Colour Wheel 1: Red Blue Green Orange Quad Colour Lime Amber Magenta Congo Blue Colour Wheel 2: Dark Red Midnight Blue Light Turquoise Pink UV Quad Colour High CRI CTO 2700K CTC (Colour Temp. Correction) Control protocols: DMX RDM sACN and ArtNet 3 DMX Channel Modes (Basic / Standard / Extended) Aria X2 Wireless Management System NFC System Pan/tilt transit lock Pan/tilt auto correction 16-Bit pan/tilt positioning Pan: 540°/360° (360° Continuous Pan Rotation Option) Tilt: 270° 3 Phase Motors 0–100% dimming Variable strobe Quick release omega clamps included 6 Button Touch Control Panel Full Colour 180° Reversible LCD Menu Display IP65 Power Locking In/Thru Seetronic 5-pin XLR Locking DMX In/Thru Seetronic RJ45 Locking In/Thru Fan cooled
Power consumption: 675W Power supply: 100~240V 50/60Hz Dimensions (H x W x D): 566.5 x 368 x 248mm Weight: 22kg
