The ADJ Focus Profile is a feature-packed moving head profile fixture with framing shutters. It features a potent 400W LED engine 4 rotating framing shutters full CMY colour mixing and two prism effects.The brightest and most feature-rich Focus Series fixture to date the Focus Profile is a professional caliber automated profile luminaire designed for theatrical concert touring and event production applications. It features a potent 400W LED engine with a native colour temperature of 6700K and a CRI in excess of 70 coupled with an exhaustive collection of beam-shaping tools. These include four independently controllable rotating full blackout framing shutter blades which can be used to precisely shape the light output. The unit offers full CMY colour mixing together with variable CTO colour temperature control (2700K to 6700K) and an additional colour wheel loaded with 6 dichroic filters comprised of four primaries together with CTB and CRI filters. Two separate GOBO wheels feature 7 replaceable indexed-rotating GOBOs and 8 static GOBOs respectively while two bi-directional rotating prisms (3-facet and 6-facet) allow for the creation of a wide variety of aerial effects. Motorized focus iris and zoom (7 – 45-degrees) together with a replaceable (medium) frost filter and an animation wheel complete the lineup of features offered by this powerful and versatile luminaire.

2 year warranty 1 x 400W white LED (6700K) Adjustable beam angle: 7°-45° Lumens: 20990 7° - 11082 Lux @ 10m 45° - 441 Lux @ 10m CRI: 70 High CRI filter (CRI: 88) Refresh rate: 900Hz-25kHz Motorised zoom focus and iris 4 rotating framing shutters +/-60° plus shape rotation 3 facet circular rotating indexable prism plus 4 facet linear rotating indexable prism Medium frost filter (replaceable heavy frost filter included) Gobo wheel 1: 7 rotating replaceable gobos + open Gobo wheel 2: 8 static gobos + open Animation wheel CMY colour mixing: Cyan 0-100% Magenta 0-100% and Yellow 0-100% Variable CTO flag (0-100%) Colour wheel: 6 dichroic colours + open DMX channels: 36/40 or 51 selectable Manual control and primary/secondary modes plus built-in programs Pan/tilt transit lock and auto correction 16-Bit pan/tilt positioning Pan: 540° or 630° selectable Tilt: 270° 0 – 100% dimming 6 dimming modes: Standard stage TV architectural theatre and stage 2 4 dimming curves: Linear square inv. square and S. curve Variable strobe Quick release omega clamps included RDM (Remote Device Management) 6 button menu with LCD display Display battery backup for offline configuration PowerTwist TR1 input/output 5-Pin XLR input/output 3-Pin XLR input/output RJ45 input/output USB port (firmware updates) Fan cooled

Manufacturer Part Number: 1237000205 Power consumption: 560W Power supply: 100~240V 50/60Hz Noise level: 36.7dBA @ 1m Dimensions (H x W x D): 651 x 400 x 260mm Weight: 27.8kg
