LOSUB is designed to offer a high power subwoofer unit with compact dimensions compared with traditional subs. Employing a downward angled baffle, the LOSUB creates a pressure zone at ground level and ports this forward, meaning that the driver is positioned to operate in a smaller enclosure. Sitting on the ground, the cabinet is just 36cm high and has a 35mm pole mount for adding a satellite full-range speaker. This low profile also enables the cabinet to fit under or beside furnishings and in narrow spaces for installation. The input section has 2 independent inputs and outputs for stereo link to a pair of active tops in a 2.1 configuration and there is an adjustable low pass filter and boost function to provide the right amount of sub output as needed. Whether is it for space-saving during transit or storage or for building into discreet spaces for installation, the LOSUB provides hefty power without eating up all your room.

Specifications

Semi-directional ported design
Compact dimensions
Stereo in/out for 2.1 operation
Power supply:230Vac, 50Hz (IEC)
Construction:MDF enclosure with polyurea finish
Hardware:Routed handles & 35mm pole mount socket
Amplifier : construction:Class-D (fixed DSP)
Inputs:2 x balanced XLR / 6.3mm jack
Outputs:2 x balanced XLR
Controls:Flat/boost, phase switch, frequency, subwoofer level
Driver:380mmØ (15") sub woofer
Frequency response:40 - 120Hz
Sensitivity @ 1W/1m:96dB
SPL max.:127dB
Voice coil:75mmØ (3")
Magnet:2.835kg (100oz)
Output power rms:600W
Output power max.:1200W
Dimensions:550 x 480 x 360mm
Weight:24kg
