The speakON STXX Series was especially designed for heavy duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable STXX Series features an all metal housing.

Manufacturer's Part Code: NLT8MXX-BAG 8-pole male speakON cable connector designed for professional audio applications Locking 30A / 250V AC-rated connector suitable for amplifier-to-loudspeaker connections Rugged black metal housing ensures durability in demanding environments Quick Lock system facilitates easy and secure connections Compatible with all Neutrik speakON 8-pole connectors for seamless integration ¼" flat tab termination for reliable and straightforward assembly Chuck-type strain relief provides secure cable retention and alignment Ergonomic design with slip-proof two-component molded housing for comfortable handling Superior Neutrik quality standard ensures exceptional robustness and reliability Enhanced kink protection through a two-component bushing design Unique Neutrik locking bushing and strain relief accommodates cable diameters from 8mm to 20mm

IEC 61984 certified compliant with IEC 62368-1 Contact resistance: ≤2mΩ Dielectric strength: >1.5kVac Insulation resistance: >0.1GΩ Overall cable diameter: 8-20mm Wire size: 1.5mm² - 6mm² (10 AWG) Rated current per contact: 30A RMS continuous Rated voltage: 250V AC Locking system: Quick Lock (latch) Termination type: ¼" flat tab connectors Temperature range: -30°C to +80°C Protection class: IP50 (when mated)
