High output ceiling loudspeakers with extended frequency response ideal for the playback of music and speech reinforcement where audio quality is important. The CS HP series utilise a coaxial design complete with HF tweeter for crystal clear high tones plus metal enclosure for enhanced low frequencies. These loudspeakers feature flush mount dog-ear retaining clips and a installation template is supplied making them simple to install. Suitable for either low impedance or 100V line operation.

3 year warranty Coaxial 2-way design delivers a wide frequency response Multiple power taps plus low impedance Rotary power tap Metal grille ABS baffle and metal enclosure Flush mount dog-ear retaining clips for easy installation Spring terminals for simple installation Supplied with template to aid installation 25mm maximum panel thickness

Input: 100V 8Ω Power taps @ 100V: 1.25W 2.5W 5W 10W 20W Impedance: 4KΩ 2KΩ 1KΩ 500Ω 400Ω Power (RMS): 20W @ 8Ω Sensitivity (1W/1m): 88dB (±3dB) Maximum SPL (Rated W/1m): 101dB Frequency response: 100Hz-20kHz Drivers: 5" LF 1.5" HF Connections: 2 x spring terminals Cutout: 180mmØ Mounting depth: 128mm Dimensions: 152 x 202mmØ Weight: 1.4kg
