The Allen & Heath SQ-5 is a professional-grade 48-channel digital mixer featuring 96kHz FPGA processing 36 buses and 16 onboard mic preamps. Designed for live sound studio recording and installations it offers ultra-low latency comprehensive I/O options and a user-friendly interface with a 7" capacitive touchscreen. With DEEP processing 8 stereo FX engines and expansion capabilities via SLink and I/O ports the SQ-5 delivers exceptional audio quality and flexibility for demanding audio environments.
48 input channels with 96kHz FPGA processing 36 buses including 12 stereo mixes and 3 stereo matrices 16 onboard XLR mic preamps with recallable settings 8 stereo FX engines with dedicated returns 7" capacitive touchscreen for intuitive control 17 motorised faders across 6 layers for flexible mixing DEEP processing architecture for embedded plugins 32x32 USB audio interface for multitrack recording SLink port for remote audio and I/O expansion 64-channel I/O port for audio networking (Dante/Waves compatible)
Mic Inputs: 16 x XLR (recallable preamps) Line Inputs: 2 x 1/4" TRS stereo pairs 1 x 1/8" stereo Analog Outputs: 12 x XLR 2 x 1/4" TRS Digital Outputs: 1 x XLR AES USB Interface: 32-in/32-out 96kHz Faders: 17 x 100mm motorised Touchscreen: 7" capacitive 800x480 resolution Processing: DEEP processing 8 RackFX engines Latency: <0.7ms Dimensions (H x W x D): 186mm x 440mm x 514mm Weight: 10.5kg (23.1 lbs)
48 input channels with 96kHz FPGA processing 36 buses including 12 stereo mixes and 3 stereo matrices 16 onboard XLR mic preamps with recallable settings 8 stereo FX engines with dedicated returns 7" capacitive touchscreen for intuitive control 17 motorised faders across 6 layers for flexible mixing DEEP processing architecture for embedded plugins 32x32 USB audio interface for multitrack recording SLink port for remote audio and I/O expansion 64-channel I/O port for audio networking (Dante/Waves compatible)
Mic Inputs: 16 x XLR (recallable preamps) Line Inputs: 2 x 1/4" TRS stereo pairs 1 x 1/8" stereo Analog Outputs: 12 x XLR 2 x 1/4" TRS Digital Outputs: 1 x XLR AES USB Interface: 32-in/32-out 96kHz Faders: 17 x 100mm motorised Touchscreen: 7" capacitive 800x480 resolution Processing: DEEP processing 8 RackFX engines Latency: <0.7ms Dimensions (H x W x D): 186mm x 440mm x 514mm Weight: 10.5kg (23.1 lbs)
Allen & Heath 48 Channel / 36 Bus Digital Mixing Console SQ5
Brand: Allen & Heath
SKU: AH0001
Regular price
£2,877.99
Pickup available at Venutec
Usually ready in 24 hours
Allen & Heath 48 Channel / 36 Bus Digital Mixing Console SQ5
-
Venutec
Pickup availableUsually ready in 24 hours
3 Waterside Court
Bone Lane
Newbury RG14 5SH
United Kingdom447404920360
Need help with choosing the right product?
Click here to reach out to one of our experts.
The Allen & Heath SQ-5 is a professional-grade 48-channel digital mixer featuring 96kHz FPGA processing 36 buses and 16 onboard mic preamps. Designed for live sound studio recording and installations it offers ultra-low latency comprehensive I/O options and a user-friendly interface with a 7" capacitive touchscreen. With DEEP processing 8 stereo FX engines and expansion capabilities via SLink and I/O ports the SQ-5 delivers exceptional audio quality and flexibility for demanding audio environments.
48 input channels with 96kHz FPGA processing 36 buses including 12 stereo mixes and 3 stereo matrices 16 onboard XLR mic preamps with recallable settings 8 stereo FX engines with dedicated returns 7" capacitive touchscreen for intuitive control 17 motorised faders across 6 layers for flexible mixing DEEP processing architecture for embedded plugins 32x32 USB audio interface for multitrack recording SLink port for remote audio and I/O expansion 64-channel I/O port for audio networking (Dante/Waves compatible)
Mic Inputs: 16 x XLR (recallable preamps) Line Inputs: 2 x 1/4" TRS stereo pairs 1 x 1/8" stereo Analog Outputs: 12 x XLR 2 x 1/4" TRS Digital Outputs: 1 x XLR AES USB Interface: 32-in/32-out 96kHz Faders: 17 x 100mm motorised Touchscreen: 7" capacitive 800x480 resolution Processing: DEEP processing 8 RackFX engines Latency: <0.7ms Dimensions (H x W x D): 186mm x 440mm x 514mm Weight: 10.5kg (23.1 lbs)
48 input channels with 96kHz FPGA processing 36 buses including 12 stereo mixes and 3 stereo matrices 16 onboard XLR mic preamps with recallable settings 8 stereo FX engines with dedicated returns 7" capacitive touchscreen for intuitive control 17 motorised faders across 6 layers for flexible mixing DEEP processing architecture for embedded plugins 32x32 USB audio interface for multitrack recording SLink port for remote audio and I/O expansion 64-channel I/O port for audio networking (Dante/Waves compatible)
Mic Inputs: 16 x XLR (recallable preamps) Line Inputs: 2 x 1/4" TRS stereo pairs 1 x 1/8" stereo Analog Outputs: 12 x XLR 2 x 1/4" TRS Digital Outputs: 1 x XLR AES USB Interface: 32-in/32-out 96kHz Faders: 17 x 100mm motorised Touchscreen: 7" capacitive 800x480 resolution Processing: DEEP processing 8 RackFX engines Latency: <0.7ms Dimensions (H x W x D): 186mm x 440mm x 514mm Weight: 10.5kg (23.1 lbs)
