5-channel 19" rack-mountable mixer-amplifier, designed for commercial sound installations to power 100V line speakers or standard low impedance speakers. Input options include XLR (with switchable phantom power), mic/line jack, and RCA line. A switchable ‘voiceover’ feature automatically lowers the background music volume when a signal is detected via mic input 1, and rear panel 24V contacts can mute all except mic input 1 when triggered. A built-in audio player section can play mp3 files from a USB or stream audio wirelessly from Bluetooth®. A main feature of the RM-WIFI models is the ability to connect to a wired or wireless network for streaming audio from internet radio, playback services or even from a local NAS drive. Setup and control for this function is entirely via the WiiM Home smart phone app with a choice of streaming services embedded. Outputs on screw terminal are via 4 switchable zones with a separate "always on" output for priority alert speakers.
USB player and Bluetooth receiver
4 switchable 100V outputs and 1 unswitched output
Optional 4-16 Ohm output
XLR input with switchable +20V phantom power
2 x mic/line inputs, 2 x RCA line inputs, 1 x RCA line output
Free WiiM Home Player app for Android or iOS
Power supply:170-264Vac, 50Hz (IEC)
DC power:24Vdc (screw terminals)
Inputs:Mic XLR, 2 x mic/line jack, 2 x RCA line
Input sensitivity : mic 1 (balanced):-53dBV
Input impedance : mic 1:5k Ohms
Input sensitivity : line (unbalanced):-15dBV (-18.5dBV line 5)
Input impedance : inputs 2-5:1k Ohms
Line output:RCA
Speaker outputs:4 switched + 1 non-switched 100V / 4-16 Ohms / COM
Bluetooth version:5.0
Controls:Mic1, mic/line2+3, line4+5, bass, treble, master volume
Equaliser : bass:100Hz ±10dB
Equaliser : treble:10kHz ±10dB
Rear panel switches:Phantom, Vox, Mic/Line (2 + 3)
Phantom power:+20V (mic 1 XLR, switchable)
Audio source:Network audio, USB player, Bluetooth receiver
Emergency control:24V contacts - mute all except Mic.1 when triggered
THD:<1.0%
Dimensions:433 x 320 x 88mm
Network connection:RJ45 (LAN) or 2.4GHz WiFi (802.11 b/g/n)
Remote control:via WiiM Home app f
Specifications
Internet radio or audio streaming from WiFi or LAN connectionUSB player and Bluetooth receiver
4 switchable 100V outputs and 1 unswitched output
Optional 4-16 Ohm output
XLR input with switchable +20V phantom power
2 x mic/line inputs, 2 x RCA line inputs, 1 x RCA line output
Free WiiM Home Player app for Android or iOS
Power supply:170-264Vac, 50Hz (IEC)
DC power:24Vdc (screw terminals)
Inputs:Mic XLR, 2 x mic/line jack, 2 x RCA line
Input sensitivity : mic 1 (balanced):-53dBV
Input impedance : mic 1:5k Ohms
Input sensitivity : line (unbalanced):-15dBV (-18.5dBV line 5)
Input impedance : inputs 2-5:1k Ohms
Line output:RCA
Speaker outputs:4 switched + 1 non-switched 100V / 4-16 Ohms / COM
Bluetooth version:5.0
Controls:Mic1, mic/line2+3, line4+5, bass, treble, master volume
Equaliser : bass:100Hz ±10dB
Equaliser : treble:10kHz ±10dB
Rear panel switches:Phantom, Vox, Mic/Line (2 + 3)
Phantom power:+20V (mic 1 XLR, switchable)
Audio source:Network audio, USB player, Bluetooth receiver
Emergency control:24V contacts - mute all except Mic.1 when triggered
THD:<1.0%
Dimensions:433 x 320 x 88mm
Network connection:RJ45 (LAN) or 2.4GHz WiFi (802.11 b/g/n)
Remote control:via WiiM Home app f
Adastra RM120-WIFI Mixer-Amp 100V
Brand: Adastra
SKU: 953.234UK
Regular price
£389.00
Pickup available at Venutec
Usually ready in 24 hours
Adastra RM120-WIFI Mixer-Amp 100V
-
Venutec
Pickup availableUsually ready in 24 hours
3 Waterside Court
Bone Lane
Newbury RG14 5SH
United Kingdom447404920360
Need help with choosing the right product?
Click here to reach out to one of our experts.
